Technical design choices for the single cell implementation

Gregor Lueg

2026-09-24

This is an opinionated piece, so take what is written here with a pinch of salt. The statements here reflect my personal opinions, not those of any of my past, current, or future employers.

Why do we need yet another single cell framework … ?

Why the hell would you write a single cell framework from scratch and not use one of the established libraries? We have in R Seurat, in the BioConductor universe single cell experiments; in Python ScanPy and even now GPU-accelerated RAPIDS-singlecell leveraging CUDA and Nvidia GPUs. In Rust, we have SingleRust which is porting ScanPy over… What the hell is the point, you might ask? Well, the design philosophy in this package is quite different from all of the above. Whether better or worse you shall discover, but it is different. Let’s start with the problem though…

Chapter 1: Single cell is just not (very) performant (on CPU)…

Some quotes from recent papers:

We benchmarked rapids-singlecell on 1 million cells from the 10x Genomics mouse brain dataset, running a standard workflow: preprocessing, normalization, HVG selection, dimensionality reduction (PCA, UMAP, t-SNE), neighborhood graph construction, and Leiden clustering (Methods). On a 32-core workstation, the pipeline took over 52 minutes (Methods) […]

• Dicks, et al., arXiv, 2026

For instance, a typical single-cell data analysis pipeline — encompassing data integration, clustering, visualisation, and differential expression analysis — requires about 16 h to process half a million cells on a standard desktop. When the cell number slightly increases to 600,000, the above pipeline can crash due to memory exceeding, even on a professional computing platform with 512 GB RAM

• Li, et al., Nat Comm, 2025

Recommendations for executing the Scanpy analysis

To avoid computer crashes and program failures, we recommend you execute the Python code on a cloud computing platform. The instance you select on the cloud platform to run this analysis should consist of at least 8 threads and 160 GB of RAM.

• Parse biosciences

Anyone who has worked with more than 500k cells can attest to it being painful. Actually VERY painful. The question is… why? Why can analytical engines like DuckDB and polars handle massive data sets without needing fat memory machines? You can easily analyse hundreds of millions of rows on a local laptop with those two. Why can we not do the same with single cell? Is the answer really “Bro, just throw more cores, memory, and GPUs at the problem”? Or is it time to rethink HOW we are doing this.

Chapter 2: Do not keep data in memory…

Let’s do some maths. Say we have a single cell experiment with 1M cells, with on average 1000 genes detected per cell. What actually happens to our memory? Worst case: R with its double precision floats.

# raw counts
x     (values, double in R by default):  1B × 8 bytes = 8 GB
                       (int32 if lucky): 1B × 4 bytes = 4 GB
i     (row indices, int32):              1B × 4 bytes = 4 GB
p     (col pointers, int32):             (1M+1) × 4   ~ 4 MB

Total: ~12 GB (double) / ~8 GB (int32)

# norm counts
For sure double, so 12 GB

# scaled counts with 2k HVG (if 3k, just increase this by 50%)
2k HVGs:  1M × 2,000 × 8 bytes = 16 GB

# embeddings
PCA:              1M × 50 × 8 = 400 MB
Batch correction: 1M × 50 × 8 = 400 MB

Total: ~800 MB

# kNN graph
indices (int32):    20M × 4 = 80 MB
data (double):      20M × 8 = 160 MB
indptr (int32):      1M × 4 =   4 MB

Total: ~244 MB

# sNN graph
Same as kNN graph ~244 MB

You are already looking at 40+ GB of occupied memory. Then you have some horrible tibbles with 1M rows; throw in a bunch of string columns and you are adding another 250–500 MB in nasty situations. Now add R’s copy-on-modify semantics and suddenly everything becomes unbearably slow, memory hungry, and you end up with bloated objects storing data you rarely actually need in memory. The question is: should we be doing any of this? Why do we keep raw and normalised counts in memory at all? BPCells is going in the right direction here, but can we do even better?

Chapter 3: Python and R are slow…

There. It has been said. They are slow and let us stop pretending otherwise. Yes, you can drop into NumPy or Rcpp for the heavy lifting, but that argument rather proves the point! The real problem is not any single kernel; it is what happens between them.

A lot of algorithms in practice end up looking like this:

R/Python → low-level kernel → R/Python → low-level kernel → R/Python → ...

Each arrow is a context switch. Data gets passed across a language boundary, some “simple” bookkeeping happens in the interpreter (a filter here, a reshape there, maybe a quick normalisation) and then you hand it back down again. None of those individual steps looks expensive. Collectively, they are death by a thousand cuts: repeated allocations, data copies you did not ask for, and the interpreter’s garbage collector doing God knows what in between. You also lose any hope of the compiler reasoning across those boundaries and optimising the full pipeline.

The solution is not to make the interpreted bits faster. It is to keep the data in low-level code for as long as possible and only surface results to R when the user actually needs to look at something. R then becomes a thin orchestration layer, not an active participant in the computation.

What is your proposal then … ?

Okay, everything so far reads like a rant. What is the solution, mate?

Let’s not keep data in memory to start with … ?

If we think this through, we can arrive at a solution. Ideally, we want an interface from an interpreted, dynamically typed language: going all-in on Rust is just too heavy. The average single cell enthuasist does not want to deal with the borrow checker, does not want to compile code, and wants to quickly analyse and iterate over data. The average bioinformatician lives in blissful ignorance and will not be able to comment on f32 vs f64 float representation in memory, when to use which and frankly should not have to. That means the interface should be a dynamically typed, interpreted language. This opens the package up to more people and makes plotting (ggplot2 and its extensions for the win) much easier. From there we can make some design decisions.

1. We do not keep data in memory if not needed! Most analyses leveraging counts only need subsets of cells and genes. We can also avoid holding metadata in memory via DuckDB. Data will be streamed from disk when needed and Rust’s compiler will free memory once it is no longer needed, sometimes enforced explicitly with drop(). Raw counts? Nope. Normalised counts? Nope. Scaled counts? Nope. We just removed 40 GB of unnecessary stuff from memory (in our 1M cell example). Data can be loaded into memory in milliseconds if need be.

2. We do not even load all data into memory to begin with. In 99.99% of cases, we know we do not want low quality cells with tiny library sizes and few unique features. We also almost always do the usual library-size-to-target-size normalisation with log transformation. (Anyone who has tried fancy Pearson residual modelling on large data sets knows what I am talking about.) That means when reading h5ad or mtx files, we can pre-scan them, take only what we want, and normalise in a single pass, avoiding the load-everything, then-filter, then-normalise pattern.

3. We accept that single cell is noisy and do not bother with f32 or even f64 precision for storage. For raw counts, u16 is sufficient most of the time, and the storage enum falls back to u32 per chunk for the rare gene that busts it, so nothing gets clipped. The ML field has shown that you can get away with f16, which reduces memory pressure and I/O substantially, and they are pushing quantisation even further than that. We will accept the precision loss when upcasting to f64 to avoid catastrophic cancellation issues at large N.

4. We are not doing any heavy calculations in R (or Python, future roadmap). Rust is superior for speed and optimisation: aggressive multi-threading, no copy-on-modify semantics, tight memory control, and SIMD acceleration for specific bottlenecks (distance calculations, averaging, summing, normalising). R here is just an interface, telling the underlying Rust code what to do. We pay for this with some long compile time while installing the package, but the speed-ups across the board are so substantial that it is worth it.

But if the data is not in memory, will this not be slow? Well, no. We store data in structures like this. One for cells:

/// CsrCellChunk
///
/// This structure is designed to store the data of a single cell in a
/// CSR-like format optimised for rapid access on disk.
#[derive(Debug)]
pub struct CsrCellChunk {
    pub data_raw: RawCounts,
    pub data_norm: Vec<F16>,
    pub library_size: usize,
    pub indices: Vec<u32>,
    pub original_index: usize,
    pub to_keep: bool,
}

One for genes (if you are even vaguely familiar with compressed sparse formats, you have probably already clocked that this is essentially CSR and CSC storage with two data layers):

/// CscGeneChunk
///
/// This structure is designed to store the data of a single gene in a
/// CSC-like format optimised for rapid access on disk.
#[derive(Encode, Decode, Serialize, Deserialize, Debug)]
pub struct CscGeneChunk {
    pub data_raw: RawCounts,
    pub data_norm: Vec<F16>,
    pub avg_exp: F16,
    pub nnz: usize,
    pub indices: Vec<u32>,
    pub original_index: usize,
    pub to_keep: bool,
}

But you are duplicating the data! Yep, indeed. But this allows extremely efficient retrieval. Want to run DGE between two groups? Only those cells are loaded via CsrCellChunks. Want to iterate over genes to identify HVGs? That goes through CscGeneChunk. A further advantage is that for quite a few analyses, we can load subsets and stream over the data rather than reading everything at once, which massively reduces the memory footprint. We still use lz4 compression to reduce the on-disk footprint, but the core philosophy is:

Disk space is cheap; memory ain’t

This approach allows fast loading of raw or normalised counts depending on what is needed, and the two-layer approach (heavily inspired by TileDB) means we avoid duplicating indices and indptr. This assumes decent SSD speeds, but most modern hardware has that covered.

Let’s not round trip into interpreted languages

Continuing from step 4, we avoid round trips to R entirely. This sidesteps R quirks like copy-on-modify. The typical approximate nearest neighbour library used in R (Annoy) actually writes the index to disk. That was Spotify’s original design and made total sense for their use case, but why are we doing this in R? No idea. The core philosophy is to take a hard look at the algorithms and methods used and, where needed, implement a highly specialised version for single cell. Some examples:

• Custom implementation of various kNN searches, all running in Rust: ann-search-rs. No on-disk index round trips, SIMD-accelerated distance calculations, optimised memory layouts, aggressive optimisations with single cell in mind. Since kNN graphs underlie a lot of downstream methods, speeding this up has a wide impact.

• PCA underlies a lot of algorithms, is a key dimensionality reduction step, and, perhaps embarrassingly, still beats fancy foundation models. A few tricks make it fast:

  • Randomised SVD to approximate PCA much faster. Instead of decomposing a matrix of millions of cells × HVGs, we reduce the problem to a few hundred cells × HVGs.
  • Smart scaling without ever densifying the matrix. As shown in the numbers above, densifying with 2k HVGs means holding a 16 GB matrix in memory for a million cells, 80 GB for five million. With smart matrix algebra, you never have to densify at all. An 80 GB problem becomes something closer to 10 GB.

• Of course there is also a library for everyone’s favourite 2D embedding generation: manifoldsR. Same philosophy: parallelise what can be parallelised, use CPU-friendly memory layouts, avoid round trips to the interpreter. Million-cell UMAP? Done in minutes on a laptop. Even good old tSNE, infamous for being slow has an FFT-accelerated version (see Linderman, et al.)

• SCENIC infers gene regulatory networks by asking, for each target gene: which transcription factors best predict its expression? It does this by training a tree ensemble per gene, using the importance scores from those trees as a proxy for regulatory influence. The trees themselves are then thrown away. Only the importance scores matter. That means we can optimise purely for speed, without caring about prediction quality at all. A few tricks compound here:

  • Rather than training one ensemble per gene independently, we share the same tree structure across a batch of genes simultaneously: the splits are chosen to reduce prediction error across all targets in the batch at once, and each gene contributes its own importance scores as a side effect. This amortises most of the cost.
  • Transcription factor expression data is quantised down to 256 bins (one byte per cell), which makes histogram construction and split evaluation very fast and cache-friendly.
  • Single cell data is sparse, most genes are zero in most cells, so rather than densifying the target matrix (which would be enormous), we exploit that sparsity directly during tree building.

  The net result is GRN inference that runs in Rust end-to-end, with no data leaving low-level code until results are ready.

These are just some examples where purpose-built code can deliver massive gains in both memory usage and speed. This allows the package to run multi-million cell analyses (the GRNs will still be slow and take hours despite my best efforts, sorry) on a decent local laptop. I have churned through 3 million cell data sets on my loyal M1 Max MacBook Pro with 64 GB with doing reading from h5ad, mt percentage detection, some cell filtering, HVG detection, PCA, kNN/sNN graph generation + clustering in <30 minutes. Something that would be completely impossible with several of the other libraries.

There is no free lunch

While this all sounds great, one significant caveat is that using this package forces you to think differently about your data. Because data is NOT in memory, we need to carefully synchronise state between:

• The binary files Rust writes to disk with specific indexing for cells and genes. Rust uses 0-indexing and R uses 1-indexing, which causes yet another headache (mostly for developers; as an end user you should never have to think about this).

• What is stored in DuckDB as metadata. This can get tricky once you start selecting subgroups of cells. In a standard workflow you might:

  1. Filter a first wave of cells/spots based on library size and number of features.
  2. Run doublet detection to remove doublets.
  3. Recheck library sizes, feature counts, transcriptional complexity, mitochondrial counts, and only then finalise your cell selection, flagged as cells_to_keep in the object.

  Any subsequent analysis (HVG detection, PCA, kNN construction, etc.) will operate on whatever is set here. This used to be THE footgun of the package. Move the cell set, forget to re-run the kNN, and you had a PCA over one set of cells sitting next to a kNN over another. Nothing complained. It either crashed deep in Rust or, much worse, quietly handed you mis-aligned biology.

  So now it complains. Every artefact that lands in the cache, the PCA, the embeddings, the kNN, the sNN graph, the MAGIC layer, carries a provenance stamp: a hash of the cell set it was computed on, plus the ids of whatever it was derived from. The kNN records the PCA it was built on and the sNN records the kNN, which is the bit that matters. Re-run the PCA on the same cells with fewer components and the kNN hanging off it is now stale, even though its own cell count never moved. A row-count check waves that straight through.

  Two things worth saying about how it is built. The stamp rides on the payload as an attribute rather than in a registry off to the side, so deleting a payload deletes its stamp and the two cannot drift apart. And it tracks provenance, not parameters: a kNN over the first 5 PCs and one over all 15 of the same PCA look identical to it. Neither of those can produce an index mismatch, which is the only thing this is here to stop.

  The response is graded rather than one blanket error. Reading a stale artefact warns, because plenty of call sites use the getters as presence probes on something they are about to overwrite anyway. Anything that hands cached indices to Rust or writes a derived result back errors outright. options(bixverse.cache_check = "error") promotes the warnings if you want no mercy, "none" turns the lot off at your own risk. Nothing is ever silently recomputed or binned: a forty minute Harmony run is not the package’s to throw away.

  None of which means you get to stop thinking about on-disk state. It only means you find out before the biology is wrong rather than after. The worked example lives in the thinking about single cells vignette.

• The “ecosystem” (quotation marks because at the moment it is just this R package and several Rust crates) is in its infancy. Stuff will break; breaking changes will likely have to be introduced at some point. If you want to contribute at the methods level, you will need to go low-level and learn Rust. The Rust code powering all of this is here.

This is a side/hobby project, mostly a labour of love. I do hope other people find it useful and at least rethink some of their assumptions.

Future directions

A fair amount of the original roadmap has landed since this was first written. Trajectory inference is in (Palantir from Setty, et al., PAGA and gene trends along pseudotime), so is a decent spread of batch correction (Harmony, Harmony v2, fastMNN, BBKNN, Seurat CCA and rPCA, with kBET, ASW and LISI to score whether any of it worked), differential expression and abundance (Wilcoxon markers, pseudobulk into limma-voom and edgeR quasi-likelihood, NEBULA, Milo, MELD), the full SCENIC stack with cisTarget, meta cells via SEACells and SuperCell, DIALOGUE, Hotspot, VISION, NMF, multi-modal CITE-seq with WNN graphs, and Symphony reference mapping. The plotting helpers moved out into bixverse.plots rather than bloating the parent package further. The reference index is the honest list.

What is still ahead:

• More methods: the approach has always been to implement what I needed or found interesting, and that will not change. Slingshot never got done and is still on the list.

• Spatial transcriptomics: Spatial data does not (yet) reach the scale of the largest single cell data sets most of the time. However, if you are analysing many Visium or similar data sets, it can become quite heavy, and a lot of current frameworks are built on top of single cell ones anyway. There are also some interesting methods that leverage the spatial grid information directly, which I find genuinely exciting. None of it exists yet though, and to be clear about what does: the graph autocorrelation in VISION and Hotspot runs over the kNN graph, not over tissue coordinates.

• GPU acceleration: GPUs are becoming increasingly accessible, and if you have the budget for data-centre-scale GPUs, please do use them. Nvidia knows what they are doing and cuBLAS is insanely fast, in ways that simply cannot be matched on CPUs. However, most people do not have several B200s lying around at home. So the GPU work goes through cubecl on the wgpu backend, which means Metal on macOS, Vulkan on Linux and DX12 on Windows off one set of kernels rather than a CUDA-only path. (A native CUDA backend is aspirational. I do not own an Nvidia GPU to test it on.) It all lives in the sister package, and there is a fair amount of it now: sparse randomised SVD for the PCA, Harmony v2 with the arrowhead inversion, kNN across exhaustive, IVF and NNDescent-into-CAGRA, k-means coarsened fast clustering, the UMAP Adam optimiser, SEACells (both Frank-Wolfe solves), Scrublet, the NMF HALS family, SCENIC’s ExtraTrees and RandomForest learners, and Pearson/Spearman correlation.

  On measured numbers, all on an M1 Max: SCENIC end to end is 2.0x for ExtraTrees and 1.8x for RandomForest, consensus NMF 3.3x, Scrublet 2.4x, correlation 1.5x against faer on CPU and 132x against base R’s cor(). Look at a single SCENIC batch against one CPU core and the GPU side is over 20x. The end-to-end figure is lower because the CPU version already uses every core you have, so you are really comparing 32 GPU cores against 10 CPU ones.

  The honest half: on Apple Silicon the GPU rarely blows the CPU out of the water, because wgpu gets you no tensor cores. Small data loses outright. SEACells measures 0.95x on a small fit and only pays off at scale, roughly 2.6x at 50k cells and 666 archetypes. UMAP needs something like 10k points before the GPU is ahead at all. The t-SNE optimiser is still CPU, GRNBoost2 stays on CPU on purpose (the tree-based learners are where the GPU helps), GPU NMF caps the rank at 128, and GPU Harmony takes a single batch covariate. BBKNN is the one thing left unticked on that package’s own roadmap, so for now that one stays on CPU.
